Outotec Wet Electrostatic Precipitator WESP
FINE DUST AND MIST ELIMINATION
בקרוב גם בעברית
Wet electrostatic precipitators are used in metallurgical and chemical processes for the final removal of fine dust and for mist elimination from gases saturated with water vapor. Outotec has decades of experience with wet electrostatic precipitators and currently provides customers with cutting-edge wet electrostatic precipitators for a wide range of applications (e.g. Acid aerosols, potash dust, dioxin)
Typically, wet electrostatic precipitators are designed using tubular-collecting electrodes in either stainless steel alloys or plastic materials. A corona discharge electrode made of high-alloy stainless steel is found in the tube’s center and is fed with high-voltage direct current.
When the process gas enters the precipitator, it is exposed to an intense electrical field induced between the high-voltage discharge electrodes and the surfaces of the collecting tubes. The particles suspended in the gas become charged and migrate – under the influence of electrostatic forces – towards the grounded surface of the collecting tubes. The precipitated particles are finally removed from the precipitator by gravity as they slowly slide down the collecting tube walls together with the condensate as a liquid waste to a discharge drain.
Efficiencies of 90-95% are reached in one pass. In case of higher requirements two passes are installed.
Tubes can be hexagonal or round. Can be made from polymers or metallic alloys.
Particles are charged by the discharge electrode (spiked rod) and attracted and caught to the collecting electrode (tube wall). The smaller the particle the longer the travel time
